Show

Tools forpreviewing, inspecting and extracting geometry and data from the assembly.

Show Beam Face Index

Displays the indexes of the Beams. Based on a global list of the Beams in the assembly.

Show Beam Index

Displays the indexes of the Beam faces.

Show Surface Model Beam Types

Displays all Beams of one selected type from the surface model.

Show Feature Errors

Shows information useful for debugging feature application errors.

Show Joining Errors

Shows information useful for debugging errors occured while attempting to join Beams.

Show Joint Types

Displays the type names of each joints in the assembly.

Show Topology Types

Displays the topologies (L, T or X) that Compas Timber recognizes at each Joint
